Multi-Sonden-Systeme

StarLab

650 MHz - 18000 MHz

StarLab is the ultimate tool for antenna pattern measurements in laboratories and production environments where space is limited, cost is critical, and the flexibility of a portable system is required.

Referenzen:

  • StarLab 6 GHz -
  • StarLab 10 GHz -
  • StarLab 18 GHz
StarLab
StarLab
StarLab
StarLab
StarLab
StarLab
StarLab
StarLab

MEASUREMENT CAPABILITIES

  • Gain
  • Directivity
  • Beamwidth
  • Cross polar discrimination
  • Sidelobe levels
  • 3D radiation pattern
  • Radiation pattern in any polarization (linear or circular)
  • Antenna efficiency
  • TRP, TIS, EIRP and EIS

MAX. SIZE OF DUT

  • 45 cm for spherical set-up
  • 2.7 m x 45 cm for cylindrical set-up
  • Specific lengths available upon request

TECHNOLOGY

  • Near-field / Spherical
  • Near-field / Cylindrical

FREQUENCY RANGE

  • StarLab 6 GHz: 650 MHz to 6 GHz
  • StarLab 18 GHz: 650 MHz to 18 GHz

MAX. WEIGHT OF DUT

  • 10 kg with styrofoam mast
  • 15 kg with heavy DUT mast

TYPICAL DYNAMIC RANGE

  • 650 MHz - 6 GHz: 70 dB
  • 6 GHz - 18 GHz: 60 dB

OVERSAMPLING

  • Arch rotation
