959 Spectrum

Introducing the new and improved Spectrum V7 data acquisition software! This is the V7 version of both 959 Acquisition and 959 DataPro modules. This upgrade supports Windows 10.

Featuring scripting capabilities, full support for calibration and measurement using multi-probe arrays by MVG, near-field to far-field transforms, and an echo reduction toolbox.

This software is designed specifically for antenna measurement requirements in the United States.

参考文献:

959 - S1 ANTENNA MEASUREMENT -
959 - S2 RCS MEASUREMENT -
959 - S3 ANTENNA & RCS MEASUREMENT -
959 - S4 RADOME MEASUREMENT

MAIN FEATURES

US specific software
Support of Windows 10
NF-FF transforms
Scripting based on MS COM technology
New flexible test parameter viewer - allows for hiding and re-ordering topics
EIRP measurement and analysis support
AL-4806 positioner – dynamic limits. Axis limits based on the position of another axis. Enhanced driver - GUI setup, built in multi-controller support, customizable homing, higher precision position reporting
PNA support for power meter and voltage
2-D beam peaks in DataPro
Quick look plots – Overlay multiple frequencies
Home axes – multiple predefined positions supported
Phase Correction – to compensate for the fluctuations in RF cables
Calibration techniques
Device tables – to account for various measurement losses, NF and FF
Echo reduction toolbox

APPLICATIONS

Far-Field Antenna
Near-Field Antenna (Using Add-On Transforms)
Radar Cross Section (RCS)
Radome
