Compact Range Feed Horns

690 MHz - 110000 MHz

Compact Range Feed Horns are a solution for illumination of CATR systems, direct range illumination and illumination of reflector antennas.

References:

LGF-11-WB-DL -
LGF-11-DL -
LGF-11-SL -
MGF-14-SL

TECHNICAL PERFORMANCE

Rotationally symmetric radiation pattern
Low cross polarization
Stable amplitude taper with frequency
Optimized reflector edge and chamber wall illumination

DESIGN

Axially corrugated aperture
High precision mechanical mounting

SURFACE TREATMENT

Surtec 650 according to MIL-C 5541E class 3

REPEATABILITY

Stiff and robust mechanical design
Standard MVG circular interface for precision centering
Precision pin for accurate polarization alignment
Precision machined
Highly reliable RF components

DELIVERED DOCUMENTS

Typical performance data (TYMEDA™)
Measured return loss data

EQUIPMENT

RF absorbers panel (available only on specified models)
Integrated polarization switch (available only on dual linear polarized models)
