Measurement Probes and Feeds

Diagonal Horns

750 MHz - 40000 MHz

Diagonal Horns are a solution for illumination of anechoic chambers, for quasi-monostatic Radar Cross Section (RCS) measurements and for far-field test ranges.

References:

DH750 -
DH3000 -
DH6500 -
DH6500-MG -
DH18000

TECHNICAL PERFORMANCE

Equalized beamwidth in the principal planes
Extremely low side-lobes
High cross polar discrimination
2.5 : 1 bandwidth or more

DESIGN

Smooth radiation pattern over the operational bandwidth
Lightweight for easy handling

SURFACE TREATMENT

Surtec 650 according to MIL-C 5541E class 3
Polyurethane paint

REPEATABILITY

Stiff and Robust mechanical design
Standard circular interface for precision centering
Precision pin for accurate polarization alignment
Precision machined product
Highly reliable coaxial connector

DELIVERED DOCUMENTS

Typical performance data (TYMEDA™)
Measured return loss data

EQUIPMENT

Mounting Flange
Integrated coaxial transition with high precision connector
