EMC-5 Anechoic Chamber

30 MHz - 18000 MHz

An EMC Chamber with 5 meter test range ensuring EMC compliance testing for Emission and Immunity testing. Ferrite and hybrid pyramidal absorbers are combined in a unique pattern within a SmartShield high performance chamber. Operating at a 5m test distance, this EMC chamber is compliant to CISPR-16-1-4 / ANSI C63.4 with a measurement zone diameter of 2 to 4 meters.

References:

EMC-5

APPLICATIONS

EMC compliance testing in accordance with Emissions & Immunity standards for all electrical & electronic products

KEY FEATURES

EMC compliance testing Emission Performance
- CISPR 16-1-4/ANSI C63.4
- NSA 30 MHz -1 GHz +/-4 dB or better @3m/ Test Volume 2.0x2.0m (DxH)
- NSA 30 MHz -1 GHz +/-4 dB or better @5m/ Test Volume 2.0x2.0m* (DxH)
EMC compliance testing Emission Performance
- CISPR 16-1-4, sVSWR
- 1 GHz - 18 GHz @3m sVSWR < 6dB 2.0x2.0m (DxH)
EMC compliance testing Immunity Performance
- IEC 61000-4-3
- 80MHz -18GHz UFA 1.5x1.5m @3m ) 0 +6dB
Extended performance options – meeting MIL STD 461F and other specifications (40GHz
EMC absorbers HyPyr-LossTM Ferrite and Hybrid absorbers for 26 MHz - 40 GHz measurements
Optimized computer modeling to enable cost effective EMC absorbers layouts
This EMC Chamber is a Bespoke and modular design enabling unlimited performance options and facilitating upgrades or relocations
This EMC Chamber is available as part of a complete turnkey package for EMC measurements
